Complete automation system with
24V D.C. motor
001V900E
Complete automation system with encoder-based control
panel, for overhead counterweighted, spring-loaded and
sectional doors. (Traction force: 500N).
£185
Complete automation system with
24V D.C. motor
001V700E
Complete automation system with control panel, for overhead
counterweighted,spring-loaded and sectional doors (Traction
force: 850N).
£249
Accessories
001V0670
Card for connecting two 12V- 1.2Ah emergency batteries
with rack.
£54
001V005
Chain guide extension L = 1.42 m / 4,66 ft for guide types:
V0679 - V0682 - V0683 - V0684.
£63
001V121
Cord release device L = 3 m / 9’8” ft to apply
to the door handle.
£21
001V122
Transmission arm for sectional doors, with distance between
the upper edge of the door and springs-pole assembly between
30 and 60 cm
£13
001V201
Transmission adapter arm for partially extended counterweighted
overhead doors. Max door height: 2.4 m / 7’9”
ft.
£77
001V0679
Chain guide L = 3.02m / 9’9” ft *Max door
height: BC = 2.4m / 7’9” ft BM = 2.25m / 7’4”
ft STA = 2.1m / 6’9” ft STB = 2.2m / 7’2”
ft.
£77
001V0682
Chain guide L = 3.52m / 11.54 ft *Max door height: BC
= 2.75m / 9’ ft BM = 2.6m / 8’5” ft
STA = 2.7m / 8’9” ft STB = 2.2m / 7’2”
ft.
£90
001V0683
Chain guide L = 4.02m / 13,18 ft *Max door height: BC
= 3.25m / 10’6” ft BM = 3.1m / 10’2”
ft STA = 3.2m / 10’5” ft STB = 2.2m / 7’2”
ft.
£105
001V0684
Chain guide L = 3.02m / 9’9” ft *Max door
height: BC = 2.4m / 7’9” ft BM = 2.25m / 7’4”
ft STA = 2.1m / 6’9” ft STB = 2.2m / 7’2”
ft.
£124
001V0685
Belt guide L = 3.02m / 9’9” ft *Max door height:
BC = 2.4m / 7’9” ft BM = 2.25m / 7’4”
ft STA = 2.1m / 6’9” ft.
£109
001V0686
Belt guide L = 3.52m / 11’5” ft *Max door
height:
BC = 2.75m / 9’ ft BM = 2.6m / 8’5”
ft STA = 2.7m / 8’9” ft.
£115
001V0688
Belt guide L = 4.02m / 13’2” ft *Max door
height:
BC = 3.25m / 10’6” ft BM = 3.1m / 10’2”
ft STA = 3.2m / 10’5” ft.
£125
001V0687
Belt guide L = 3.02m / 9’9” ft *Max door height:
BC = 2.4m / 7’9” ft BM = 2.25m / 7’4”
ft STA = 2.1m / 6’9” ft STB = 2.2m / 7’2”
ft.
£114
NOTE:
BC = Counter-weighted Overhead
BM = Spring-loaded Overhead
STA = Type A Sectional
STB = Type B Sectional
